PS4 (ADP-240CR) Console Power Supply Adapter

PS4 (ADP-240CR) Console Power Supply Adapter Description

The ADP-240CR is an internal power supply adapter designed for certain PS4 models (CUH-11XX series). This unit converts AC power from a wall outlet into the DC power required for the PlayStation 4’s internal components, ensuring stable performance.

Technical Specifications:

• Model Number: ADP-240CR

• Console Compatibility: PS4 (CUH-11XX series)

• Input Voltage: 100-240V AC, 50/60Hz (Universal voltage support)

• Output Voltage:

  • +12V DC

  • +5V DC (Standby power)

• Power Output: 240W

• Connector Type: Proprietary PS4 power connector

• Form Factor: Internal PSU unit

Key Features:

✅ Higher Power Output (240W): Compared to later Slim models, this PSU provides more power to support the original PS4’s hardware.
✅ Universal Voltage Support: Works worldwide without needing a voltage converter.
✅ Efficient Cooling Design: Built with a compact yet effective cooling system to prevent overheating.
✅ Stable Power Delivery: Ensures smooth gaming performance without power fluctuations.

Common Issues & Troubleshooting:

1️⃣ PS4 Won’t Turn On
✔ Check power cable, wall outlet, and PSU fuse.

2️⃣ Random Shutdowns or Power Loss
✔ Ensure proper ventilation and check for overheating issues.

3️⃣ Burning Smell or Overheating PSU
✔ If the PSU is overheating or producing a burning smell, it may be damaged and needs replacement.

Replacement & Compatibility:

• If the ADP-240CR PSU is faulty, it can be replaced with the same model or a compatible aftermarket unit.

• Available on Amazon, eBay, AliExpress, and local repair shops.

How to Replace the PS4 (ADP-240CR) Console Power Supply Adapter

If your PS4 (CUH-11XX series) is not turning on, shutting down randomly, or experiencing power issues, you may need to replace the ADP-240CR power supply unit (PSU). Follow this step-by-step guide to safely replace it.

Required Tools & Parts:

✅ Replacement PSU: ADP-240CR (Ensure it’s compatible)
✅ Torx T8 / T9 Security Screwdriver
✅ Phillips #1 Screwdriver
✅ Plastic Pry Tool or Spudger (for opening the case)
✅ Compressed Air & Brush (for dust cleaning)

Step-by-Step Replacement Guide

Step 1: Power Off & Unplug the Console

1. Completely shut down the PS4 (do not leave it in Rest Mode).

2. Unplug all cables, including the power cord, HDMI, USB, and controllers.

Step 2: Remove the Top Cover

1. Place the PS4 on a flat surface with the PlayStation logo facing up.

2. Gently slide the top cover off to reveal the internal components.

Step 3: Unscrew and Remove the Power Supply Unit (PSU)

1. Locate the ADP-240CR power supply unit (a large black box near the back of the console).

2. Use a Torx T8/T9 screwdriver to remove the screws holding the PSU in place.

3. Carefully lift the PSU slightly—it is still connected by a power cable.

Step 4: Disconnect the Power Supply Cables

1. Identify the main power connector that connects the PSU to the motherboard.

2. Gently pull out the connector—do not force it, as it may break.

3. Lift and remove the ADP-240CR PSU from the console.

Step 5: Install the New Power Supply

1. Take the replacement ADP-240CR PSU and align it in the correct position inside the PS4.

2. Reconnect the power cable securely into the new PSU.

3. Place the PSU back into position and tighten the screws.

Step 6: Reassemble the Console

1. Slide the top cover back onto the PS4.

2. Reconnect all cables (power, HDMI, controllers, etc.).

3. Power on the PS4 and check if it’s working properly.

✔ Final Checks

✅ PS4 Turns On Successfully? 🎮 Great, you’re ready to play!
❌ Still Not Working? Check if the power cable or new PSU is faulty.
